רמקול ר.ס.פ מוגבר עם בלוטות’ "15 אקטיבי מקצועי מסדרת 9 ART של RCF

רמקול ר.ס.פ מוגבר עם בלוטות’ "15 אקטיבי מקצועי מסדרת 9 ART של RCF

ACOUSTICAL SPECIFICATIONS

• Frequency Response:45 Hz ÷ 20000 Hz
• Frequency Response:45 Hz ÷ 20000 Hz
• Max SPL @ 1m:131 dB
• Max SPL @ 1m:131 dB
• Horizontal coverage angle:100°
• Horizontal coverage angle:100°
• Vertical coverage angle:60°
• Vertical coverage angle:60°

TRANSDUCERS

• Compression Driver:1 x 1.0'', 1.75'' v.c
• Compression Driver:1 x 1.0'', 1.75'' v.c
• Woofer:15'', 2.5'' v.c
• Woofer:15'', 2.5'' v.c

INPUT/OUTPUT SECTION

• Input signal:bal/unbal
• Input signal:bal/unbal
• Input connectors:Combo XLR/Jack
• Input connectors:Combo XLR/Jack
• Output connectors:XLR
• Output connectors:XLR

PROCESSOR SECTION

• Crossover Frequencies:1600Hz
• Crossover Frequencies:1600Hz
• Protections:Thermal, RMS
• Protections:Thermal, RMS
• Limiter:Soft Limiter
• Limiter:Soft Limiter
• Controls:Color touch panel, data entry/volume encoder, dedicated App for iOS and Android.
• Controls:Color touch panel, data entry/volume encoder, dedicated App for iOS and Android.

POWER SECTION

• Total Power:2100 W Peak, 1050 W RMS
• Total Power:2100 W Peak, 1050 W RMS
• High frequencies:700 W Peak, 350 W RMS
• High frequencies:700 W Peak, 350 W RMS
• Low frequencies:1400 W Peak, 700 W RMS
• Low frequencies:1400 W Peak, 700 W RMS
• Cooling:Convection
• Cooling:Convection
• Connections:VDE
• Connections:VDE

ELECTRONIC SPECIFICATIONS

• Frequency Response:20 Hz ÷ 20 Hz
• Frequency Response:20 Hz ÷ 20 Hz
• THD+N, 20dB gain, 0dBu out0.005% A-Weighted
• THD+N, 20dB gain, 0dBu out0.005% A-Weighted

PROCESSING

• Processing Channels:6
• Processing Channels:6
• Signal Processing:24 Bit
• Signal Processing:24 Bit
• A/D-D/A conversion:32 Bit @ 48.0 kHz
• A/D-D/A conversion:32 Bit @ 48.0 kHz
• Dynamic range:110
• Dynamic range:110

INPUTS

• Mic:2
• Mic:2
• Remote Controlled Storable Gain:Yes
• Remote Controlled Storable Gain:Yes
• Gain Range:0 dB ÷ 42 dB
• Gain Range:0 dB ÷ 42 dB
• Input Noise Level:-114 dBu A-Weighted
• Input Noise Level:-114 dBu A-Weighted
• Mic Inputs Impedance:6 kohm
• Mic Inputs Impedance:6 kohm
• Low Cut:20 Hz ÷ 400 Hz
• Low Cut:20 Hz ÷ 400 Hz
• Phantom Power +48V:Yes
• Phantom Power +48V:Yes
• Mono Line:2
• Mono Line:2
• Gain Selection:0 dB ÷ 22 dB
• Gain Selection:0 dB ÷ 22 dB
• Line Input Impedance:21 kohm
• Line Input Impedance:21 kohm
• A/D Dynamic range:114 dB
• A/D Dynamic range:114 dB
• Stereo Line:1
• Stereo Line:1
• Gain Selection:0 dB ÷ 10 dB
• Gain Selection:0 dB ÷ 10 dB
• Stereo Line Input Impedance (kOhm)13 kohm
• Stereo Line Input Impedance (kOhm)13 kohm

OUTPUTS

• Main MIX:1
• Main MIX:1

OUTPUTS SPECIFICATIONS

• Main Out Impedance:150 ohm
• Main Out Impedance:150 ohm
• Main Out Level:22 dBu
• Main Out Level:22 dBu
• D/A Dynamic Range:114 dB
• D/A Dynamic Range:114 dB

COMPRESSORS

• RCF Compressors:Compressors on MIC/LINE CH1 & CH2 inputs.
• RCF Compressors:Compressors on MIC/LINE CH1 & CH2 inputs.

EQ

• Input Channels EQ:2 Shelving 1
• Input Channels EQ:2 Shelving 1
• Description:3 Band EQ: High and Low band shelving, MID band peak on IN
• Description:3 Band EQ: High and Low band shelving, MID band peak on IN
• -5 Band EQ: 4 Full Parametric, 1 High Shelving and HPF 24 dB/Oct on Amplifier and MAIN output,
• -5 Band EQ: 4 Full Parametric, 1 High Shelving and HPF 24 dB/Oct on Amplifier and MAIN output,

INTERNAL EFFECTS

• Send Effects:1
• Send Effects:1

MASTERING PROCESSORS

• Main OUT type:MIX OUT, CROSSOVER OUT with RCF SUBWOOFERS presets, STEREO OUTPUT, CH1 LINK OUT.
• Main OUT type:MIX OUT, CROSSOVER OUT with RCF SUBWOOFERS presets, STEREO OUTPUT, CH1 LINK OUT.

STANDARD COMPLIANCE

• Safety agency:CE compliant
• Safety agency:CE compliant

PHYSICAL SPECIFICATIONS

• Cabinet/Case Material:PP Composite
• Cabinet/Case Material:PP Composite
• Hardware:1 x M10 top, 1 x M10 each side
• Hardware:1 x M10 top, 1 x M10 each side
• Handles:1 top, 1 each side
• Handles:1 top, 1 each side
• Pole mount/Cap:Yes
• Pole mount/Cap:Yes
• Grille:Steel
• Grille:Steel
• Color:Black
• Color:Black

SIZE

• Height:717 mm / 28.23 inches
• Height:717 mm / 28.23 inches
• Width:415 mm / 16.34 inches
• Width:415 mm / 16.34 inches
• Depth:410 mm / 16.14 inches
• Depth:410 mm / 16.14 inches
• Weight:21.8 kg / 48.06 lbs
• Weight:21.8 kg / 48.06 lbs

SHIPPING INFORMATION

• Package Height:760 mm / 29.92 inches
• Package Height:760 mm / 29.92 inches
• Package Width:470 mm / 18.5 inches
• Package Width:470 mm / 18.5 inches
• Package Depth:475 mm / 18.7 inches
• Package Depth:475 mm / 18.7 inches
• Package Weight:24 kg / 52.91 lbs
• Package Weight:24 kg / 52.91 lbs
